The small combined air filling and cutting machine integrates inflation and precision cutting into one automated system. It operates with a pneumatic control mechanism and high-precision mechanical components. The scroll-type air pump generates adjustable airflow from 0.3 to 0.9 MPa, distributed evenly through multi-orifice nozzles. The cutting system, powered by a servo motor with optical grating positioning, achieves cutting accuracy within ±0.2 mm. Its modular design includes pneumatic control, material feeding, optional temperature regulation, and cutting modules, all synchronized by a PLC system.

With a 5-inch HMI touchscreen, the machine allows easy adjustments for parameters such as pressure, length, and speed. It has a 2.2 kW power rating and a maximum speed of 25 m/min, processing materials ranging from 0.03 to 0.25 mm thick. Built with stainless steel components, the vacuum adsorption platform ensures material flatness, and operational noise remains below 70 dB.

This machine produces inflatable packaging, such as air column bags and bubble films, with daily outputs of 8,000 to 15,000 linear meters for products ranging from 100 to 600 mm in width. It is also used in the medical industry for ice packs and inflatable splints, with medical-grade models featuring HEPA filters. In food packaging, it makes inflatable candy wrappers and coffee bean buffers, using FDA-compliant materials. Additionally, it produces industrial protective cushions and sports protective gear.

The standard working width is 500 mm, with customization available from 300 mm to 1200 mm. Inflation pressure can reach up to 0.9 MPa, with a flow range of 5–30 L/min. The cutting precision is ±0.1 mm, with a cutting rate of 60 cycles per minute. An optional temperature control system operates up to 200°C with ±1°C accuracy.

The dual air path enables simultaneous inflation and suction, and IoT-enabled models support remote monitoring via 4G/5G connectivity. Energy consumption is 30% lower than conventional models, with standby power under 100 W. The system also includes safety features like two-hand operation buttons and safety light curtains, compliant with CE standards.

We provide high-efficiency machines built for precision and durability. With years of experience, our solutions are tailored to your needs, optimizing your production processes. Whether in packaging, medical, or industrial sectors, our equipment enhances operational performance. Contact us today to learn more!
