W11 Series 3 roller rolling machine

W11 Series  3 roller rolling machine
W11 Series  3 roller rolling machine
W11 Series  3 roller rolling machine
W11 Series  3 roller rolling machine

W11 Series  3 roller rolling machine

W11 Series  3 roller rolling machine(图1)


The CNC three-roll bending machine adopts international advanced technology, is controlled by programmable PLC control, and is fully hydraulically driven. It is a heavy-duty CNC bending machine that can realize automatic bending. It is a multi-section curve, square circle, arc, Conical and other special shaped workpieces.



Working principle

W11 Series  3 roller rolling machine(图2)

Working parameters

TYPE
Max. Plate Thcikness(mm)
Max. Width (mm)
Max. prebend thickness(mm)
Top Roller dia(mm)
Bottom Roller Dia(mm)
Roller centre-to-centre spacing (mm)
Main Motor Power(kw)
Hydraulic motor Power (kw)
6*1500
6
1500
4.5
175
125
160
3
2.2
6*2000
6
2000
4.5
205
125
160
4
2.2
6*2500
6
2500
4.5
235
135
180
4
2.2
6*3200
6
3200
4.5
245
145
200
7.5
4
8*2000
8
2000
6
235
135
180
5.5
2.2
8*2500
8
2500
6
245
145
200
7.5
4
12*2000
12
2000
9
255
150
245
7.5
4
12*2500
12
2500
9
300
165
270
11
5.5
12*3000
12
3000
9
320
180
300
15
5.5
16*2000
16
2000
12
300
165
270
11
5.5
16*2500
16
2500
12
320
180
300
15
5.5
16*3200
16
3200
12
380
200
330
22
7.5
20*2000
20
2000
16
320
180
300
15
5.5
20*2500
20
2500
16
380
200
330
22
7.5
25*2000
25
2000
20
380
200
330
22
7.5
25*2500
25
2500
20
410
235
380
30
11
30*2000
30
2000
25
410
235
380
30
11
30*2500
30
2500
25
460
260
420
37
15
30*3000
30
3000
25
480
260
420
37
15
30*3200
30
3200
25
510
275
460
45
15
30*4000
30
4000
25
590
290
500
45
22
40*2000
40
2000
32
480
260
420
37
22
40*2500
40
2500
32
520
290
500
55
22
40*3000
40
3000
32
560
290
500
55
22
40*4000
40
4000
32
660
360
650
75
22
50*3200
50
3200
40
650
480
700
75
22
50*4000
50
4000
40
780
440
820
90
22
60*3000
60
3000
50
710
420
780
90
22
60*4000
60
4000
50
840
480
920
110
30
60*5000
60
5000
50
940
520
1000
110
30


Product detail presentation

W11 Series  3 roller rolling machine(图3)

W11 Series  3 roller rolling machine(图4)

W11 Series  3 roller rolling machine(图5)
